Traffic Analysis for 1 --

System: in
Maintainer:
Description:RMON-Port--1-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/1
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 4:50:48.
`Daily' Graph (5 Minute Average)
day
Max  In: 8808.0 b/s (0.0%) Average  In: 96.0 b/s (0.0%) Current  In: 72.0 b/s (0.0%)
Max  Out: 261.6 kb/s (0.3%) Average  Out: 2688.0 b/s (0.0%) Current  Out: 3144.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 408.0 b/s (0.0%) Average  In: 16.0 b/s (0.0%) Current  In: 64.0 b/s (0.0%)
Max  Out: 7504.0 b/s (0.0%) Average  Out: 432.0 b/s (0.0%) Current  Out: 4144.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 216.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 80.0 b/s (0.0%)
Max  Out: 5272.0 b/s (0.0%) Average  Out: 96.0 b/s (0.0%) Current  Out: 3624.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 56.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 56.0 b/s (0.0%)
Max  Out: 1504.0 b/s (0.0%) Average  Out: 8.0 b/s (0.0%) Current  Out: 1512.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
