Traffic Analysis for 48 --

System: in
Maintainer:
Description:RMON-Port-48-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/48
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 4:50:47.
`Daily' Graph (5 Minute Average)
day
Max  In: 3648.0 b/s (0.0%) Average  In: 32.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 18.3 kb/s (0.0%) Average  Out: 3312.0 b/s (0.0%) Current  Out: 3128.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 920.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 12.2 kb/s (0.0%) Average  Out: 784.0 b/s (0.0%) Current  Out: 3752.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 224.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 6464.0 b/s (0.0%) Average  Out: 184.0 b/s (0.0%) Current  Out: 3592.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 24.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 24.0 b/s (0.0%)
Max  Out: 3088.0 b/s (0.0%) Average  Out: 8.0 b/s (0.0%) Current  Out: 3088.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
