Traffic Analysis for 30 --

System: in
Maintainer:
Description:RMON-Port-30-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/30
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 4:50:47.
`Daily' Graph (5 Minute Average)
day
Max  In: 174.7 kb/s (0.2%) Average  In: 3640.0 b/s (0.0%) Current  In: 408.0 b/s (0.0%)
Max  Out: 177.6 kb/s (0.2%) Average  Out: 7440.0 b/s (0.0%) Current  Out: 3808.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 42.3 kb/s (0.0%) Average  In: 760.0 b/s (0.0%) Current  In: 1640.0 b/s (0.0%)
Max  Out: 45.7 kb/s (0.0%) Average  Out: 1640.0 b/s (0.0%) Current  Out: 4920.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 23.5 kb/s (0.0%) Average  In: 192.0 b/s (0.0%) Current  In: 14.9 kb/s (0.0%)
Max  Out: 27.8 kb/s (0.0%) Average  Out: 400.0 b/s (0.0%) Current  Out: 18.6 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 2696.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 2704.0 b/s (0.0%)
Max  Out: 5984.0 b/s (0.0%) Average  Out: 24.0 b/s (0.0%) Current  Out: 5992.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
