Traffic Analysis for 7 --

System: in
Maintainer:
Description:RMON-Port--7-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/7
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 24.5 kb/s (0.0%) Average  In: 1768.0 b/s (0.0%) Current  In: 2528.0 b/s (0.0%)
Max  Out: 89.0 kb/s (0.1%) Average  Out: 11.2 kb/s (0.0%) Current  Out: 7016.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 9888.0 b/s (0.0%) Average  In: 336.0 b/s (0.0%) Current  In: 1416.0 b/s (0.0%)
Max  Out: 39.1 kb/s (0.0%) Average  Out: 2184.0 b/s (0.0%) Current  Out: 8112.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 4696.0 b/s (0.0%) Average  In: 72.0 b/s (0.0%) Current  In: 3160.0 b/s (0.0%)
Max  Out: 24.2 kb/s (0.0%) Average  Out: 472.0 b/s (0.0%) Current  Out: 14.7 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 1112.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 1120.0 b/s (0.0%)
Max  Out: 7656.0 b/s (0.0%) Average  Out: 24.0 b/s (0.0%) Current  Out: 7664.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
