Traffic Analysis for 4 --

System: in
Maintainer:
Description:RMON-Port--4-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/4
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 15.1 kb/s (0.0%) Average  In: 1920.0 b/s (0.0%) Current  In: 48.0 b/s (0.0%)
Max  Out: 123.9 kb/s (0.1%) Average  Out: 11.5 kb/s (0.0%) Current  Out: 3160.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 10.3 kb/s (0.0%) Average  In: 368.0 b/s (0.0%) Current  In: 2360.0 b/s (0.0%)
Max  Out: 44.9 kb/s (0.0%) Average  Out: 2336.0 b/s (0.0%) Current  Out: 10.9 kb/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 5888.0 b/s (0.0%) Average  In: 80.0 b/s (0.0%) Current  In: 3080.0 b/s (0.0%)
Max  Out: 27.5 kb/s (0.0%) Average  Out: 520.0 b/s (0.0%) Current  Out: 16.5 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 1488.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 1488.0 b/s (0.0%)
Max  Out: 8128.0 b/s (0.0%) Average  Out: 32.0 b/s (0.0%) Current  Out: 8136.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
