Traffic Analysis for 23 --

System: in
Maintainer:
Description:RMON-Port-23-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/23
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 36.3 kb/s (0.0%) Average  In: 3576.0 b/s (0.0%) Current  In: 2848.0 b/s (0.0%)
Max  Out: 936.0 kb/s (0.9%) Average  Out: 43.0 kb/s (0.0%) Current  Out: 22.7 kb/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 125.5 kb/s (0.1%) Average  In: 1208.0 b/s (0.0%) Current  In: 4240.0 b/s (0.0%)
Max  Out: 468.8 kb/s (0.5%) Average  Out: 10.2 kb/s (0.0%) Current  Out: 35.0 kb/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 35.4 kb/s (0.0%) Average  In: 296.0 b/s (0.0%) Current  In: 2808.0 b/s (0.0%)
Max  Out: 155.2 kb/s (0.2%) Average  Out: 2408.0 b/s (0.0%) Current  Out: 14.6 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 3960.0 b/s (0.0%) Average  In: 16.0 b/s (0.0%) Current  In: 3184.0 b/s (0.0%)
Max  Out: 33.0 kb/s (0.0%) Average  Out: 120.0 b/s (0.0%) Current  Out: 33.0 kb/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
