Traffic Analysis for 20 --

System: in
Maintainer:
Description:RMON-Port-20-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/20
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 7560.0 b/s (0.0%) Average  In: 184.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 47.5 kb/s (0.0%) Average  Out: 1568.0 b/s (0.0%) Current  Out: 0.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 2864.0 b/s (0.0%) Average  In: 40.0 b/s (0.0%) Current  In: 408.0 b/s (0.0%)
Max  Out: 13.1 kb/s (0.0%) Average  Out: 392.0 b/s (0.0%) Current  Out: 3656.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 1160.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 232.0 b/s (0.0%)
Max  Out: 8008.0 b/s (0.0%) Average  Out: 88.0 b/s (0.0%) Current  Out: 1752.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 184.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 184.0 b/s (0.0%)
Max  Out: 1536.0 b/s (0.0%) Average  Out: 8.0 b/s (0.0%) Current  Out: 1544.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
