Traffic Analysis for 17 --

System: in
Maintainer:
Description:RMON-Port-17-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/17
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 5400.0 b/s (0.0%) Average  In: 264.0 b/s (0.0%) Current  In: 8.0 b/s (0.0%)
Max  Out: 28.2 kb/s (0.0%) Average  Out: 4008.0 b/s (0.0%) Current  Out: 3120.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 4288.0 b/s (0.0%) Average  In: 88.0 b/s (0.0%) Current  In: 8.0 b/s (0.0%)
Max  Out: 16.8 kb/s (0.0%) Average  Out: 1040.0 b/s (0.0%) Current  Out: 3016.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 1448.0 b/s (0.0%) Average  In: 24.0 b/s (0.0%) Current  In: 488.0 b/s (0.0%)
Max  Out: 10.6 kb/s (0.0%) Average  Out: 248.0 b/s (0.0%) Current  Out: 5696.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 456.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 456.0 b/s (0.0%)
Max  Out: 4024.0 b/s (0.0%) Average  Out: 16.0 b/s (0.0%) Current  Out: 4024.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
