Traffic Analysis for 15 --

System: in
Maintainer:
Description:RMON-Port-15-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/15
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 89.6 kb/s (0.1%) Average  In: 2248.0 b/s (0.0%) Current  In: 1408.0 b/s (0.0%)
Max  Out: 97.2 kb/s (0.1%) Average  Out: 4680.0 b/s (0.0%) Current  Out: 6648.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 44.5 kb/s (0.0%) Average  In: 432.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 60.6 kb/s (0.1%) Average  Out: 1000.0 b/s (0.0%) Current  Out: 0.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 11.2 kb/s (0.0%) Average  In: 104.0 b/s (0.0%) Current  In: 584.0 b/s (0.0%)
Max  Out: 20.0 kb/s (0.0%) Average  Out: 224.0 b/s (0.0%) Current  Out: 4272.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 1840.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 1848.0 b/s (0.0%)
Max  Out: 3672.0 b/s (0.0%) Average  Out: 16.0 b/s (0.0%) Current  Out: 3672.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
