Traffic Analysis for 14 --

System: in
Maintainer:
Description:RMON-Port-14-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/14
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 15.3 kb/s (0.0%) Average  In: 208.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 139.5 kb/s (0.1%) Average  Out: 3424.0 b/s (0.0%) Current  Out: 0.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 3024.0 b/s (0.0%) Average  In: 40.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 46.0 kb/s (0.0%) Average  Out: 688.0 b/s (0.0%) Current  Out: 16.0 b/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 1000.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 40.0 b/s (0.0%)
Max  Out: 9160.0 b/s (0.0%) Average  Out: 136.0 b/s (0.0%) Current  Out: 3568.0 b/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 192.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 192.0 b/s (0.0%)
Max  Out: 2600.0 b/s (0.0%) Average  Out: 8.0 b/s (0.0%) Current  Out: 2600.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
