Traffic Analysis for 11 --

System: in
Maintainer:
Description:RMON-Port-11-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/11
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 14.1 kb/s (0.0%) Average  In: 2224.0 b/s (0.0%) Current  In: 8.0 b/s (0.0%)
Max  Out: 89.6 kb/s (0.1%) Average  Out: 12.6 kb/s (0.0%) Current  Out: 3120.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 7776.0 b/s (0.0%) Average  In: 416.0 b/s (0.0%) Current  In: 6080.0 b/s (0.0%)
Max  Out: 33.0 kb/s (0.0%) Average  Out: 2472.0 b/s (0.0%) Current  Out: 33.0 kb/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 4352.0 b/s (0.0%) Average  In: 96.0 b/s (0.0%) Current  In: 3992.0 b/s (0.0%)
Max  Out: 24.2 kb/s (0.0%) Average  Out: 560.0 b/s (0.0%) Current  Out: 18.6 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 1624.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 1632.0 b/s (0.0%)
Max  Out: 9664.0 b/s (0.0%) Average  Out: 32.0 b/s (0.0%) Current  Out: 9672.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
