Traffic Analysis for 10 --

System: in
Maintainer:
Description:RMON-Port-10-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/10
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:50,
at which time the device had been up for 4 days, 3:13:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 21.5 kb/s (0.0%) Average  In: 2208.0 b/s (0.0%) Current  In: 3368.0 b/s (0.0%)
Max  Out: 184.0 kb/s (0.2%) Average  Out: 15.6 kb/s (0.0%) Current  Out: 13.6 kb/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 7848.0 b/s (0.0%) Average  In: 416.0 b/s (0.0%) Current  In: 2696.0 b/s (0.0%)
Max  Out: 109.8 kb/s (0.1%) Average  Out: 2904.0 b/s (0.0%) Current  Out: 16.9 kb/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 5624.0 b/s (0.0%) Average  In: 96.0 b/s (0.0%) Current  In: 4008.0 b/s (0.0%)
Max  Out: 43.7 kb/s (0.0%) Average  Out: 664.0 b/s (0.0%) Current  Out: 17.7 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 1192.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 1192.0 b/s (0.0%)
Max  Out: 10.1 kb/s (0.0%) Average  Out: 32.0 b/s (0.0%) Current  Out: 10.1 kb/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
