Traffic Analysis for 36 --

System: in
Maintainer:
Description:RMON-Port-36-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/36
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:45,
at which time the device had been up for 3 days, 5:17:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 85.3 kb/s (0.1%) Average  In: 1160.0 b/s (0.0%) Current  In: 4128.0 b/s (0.0%)
Max  Out: 154.9 kb/s (0.2%) Average  Out: 15.0 kb/s (0.0%) Current  Out: 25.6 kb/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 18.7 kb/s (0.0%) Average  In: 208.0 b/s (0.0%) Current  In: 8.0 b/s (0.0%)
Max  Out: 46.7 kb/s (0.0%) Average  Out: 2680.0 b/s (0.0%) Current  Out: 27.0 kb/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 5784.0 b/s (0.0%) Average  In: 48.0 b/s (0.0%) Current  In: 2032.0 b/s (0.0%)
Max  Out: 34.9 kb/s (0.0%) Average  Out: 600.0 b/s (0.0%) Current  Out: 34.9 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 1112.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 1120.0 b/s (0.0%)
Max  Out: 8576.0 b/s (0.0%) Average  Out: 24.0 b/s (0.0%) Current  Out: 8576.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
