Traffic Analysis for 22 --

System: in
Maintainer:
Description:RMON-Port-22-on-Unit-1
ifType: ethernetCsmacd (6)
ifName: 1/22
Max Speed: 12.5 MBytes/s
The statistics were last updated Thursday, 27 October 2005 at 18:45,
at which time the device had been up for 3 days, 5:17:46.
`Daily' Graph (5 Minute Average)
day
Max  In: 960.0 b/s (0.0%) Average  In: 88.0 b/s (0.0%) Current  In: 0.0 b/s (0.0%)
Max  Out: 32.8 kb/s (0.0%) Average  Out: 10.7 kb/s (0.0%) Current  Out: 1384.0 b/s (0.0%)
`Weekly' Graph (30 Minute Average)
week
Max  In: 272.0 b/s (0.0%) Average  In: 16.0 b/s (0.0%) Current  In: 8.0 b/s (0.0%)
Max  Out: 27.3 kb/s (0.0%) Average  Out: 1920.0 b/s (0.0%) Current  Out: 26.9 kb/s (0.0%)
`Monthly' Graph (2 Hour Average)
month
Max  In: 176.0 b/s (0.0%) Average  In: 8.0 b/s (0.0%) Current  In: 160.0 b/s (0.0%)
Max  Out: 26.4 kb/s (0.0%) Average  Out: 400.0 b/s (0.0%) Current  Out: 25.5 kb/s (0.0%)
`Yearly' Graph (1 Day Average)
year
Max  In: 72.0 b/s (0.0%) Average  In: 0.0 b/s (0.0%) Current  In: 72.0 b/s (0.0%)
Max  Out: 4328.0 b/s (0.0%) Average  Out: 8.0 b/s (0.0%) Current  Out: 4336.0 b/s (0.0%)

GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
